Low Temperature Drying Cabinet

  • Low Temperature Drying Cabinet
  • Low Temperature Drying Cabinet
  • Low Temperature Drying Cabinet
  • Low Temperature Drying Cabinet

Low Temperature Drying Cabinet

    Payment Type: L/C,T/T,Western Union
    Terms of Trade: FOB
    Min. Order: 1 Set/Sets
    Delivery Time: 30 Days
    Packaging: Wood Box
    Productivity: 30-50 Set per Year
    Brand: Hywell
    Transportation: Ocean
    Place of Origin: China
    Supply Ability: 5-10 Set/Sets per Year
    Certificate: ISO CE
    HS Code: 8419399090
    Port: Shanghai

Basic Info

Model No.: CT-C

Product Description

Low Temperature Drying Cabinet


Features:

1.Hot Air Drier ,Control system has more choices, such as push button, HMI+PLC and so on

2.Hot Air Dryer ,For the heating system for the machine , it is very flexible. we can configure it based on the customer site conditions ,such as steam ,electricity.

3.CE Approved Hot Air Dryer have the CE certificate.

CT-C series Hot Air Dryer is equipped with low noise axial flow fan and automatic Temperature control system.

Most of hot air is circled inside the dry oven, thus rendering hot efficiency very high and saving energy source. It is applied to intensify ventilation and equipped in the adjustable air distributing plate inside the dry oven. And Food Dryer Equipment can use dried raw material and heat source, involving steam, hot water, electricity or far infrared. This machine features low noise and stable operation, with automatically controlled temperature. The applied fields are wide and can be suitable for all kinds of raw materials. It is a comprehensive.


Advantage
1. Most hot air is circulated in the oven. The heat efficiency is high and the energy is saved. By using the forced ventilating function, there are adjustable air distribution plates inside the oven, the materials can be dried uniformly.

2. The heating source might be steam, hot water, electricity and far infrared, with a wide selection.

3. The whole machine is low in the noise. The operation is in balance.

4. The temperature is controlled automatically. The installation and maintenance are easy. The application is wide.

5. The machine can be used for drying various materials.

Application
This drying oven is suitable for material and product hot solidification and dry de-watering in the pharmaceutical, chemical, food, farming side-product, aquatic product, light industries, heavy industries and others industries. Such as: raw material medicine, crude drug, prepared herbal medicine of Chinese traditional medicine, plaster, powder, particle, drinking agent, pill, packing bottle, pigment, dyestuff, dewatering vegetable, dried fruit piece, sausage, plastics, resin, electric component, baking varnish and etc.

Optional Choices
1. For the main electrical components , we have international brand choices such as ABB , Siemens or Schneider or others.
2. For the material for the machine , we have choices on AISISUS304 , AISISUS316L,carbon steel and so on .
3. For the control system , we have choices on push button, PLC+HMI and so on .
4. For the heating system for the machine , it is very flexible. we can configure it based on the customer site conditions ,such as steam ,electricity.

5. If without heating system , it can as a cooler to make particle with cooling air.


About Us:
From dryer, mixer to granulator, from unit machine to production line, we have them all. Hywell Machinery is a professional manufacturer of industrial Drying Machine, mixing machine and granulating machine. Our flagship products include the hot air dryer, vibration fluid bed dryer, belt dryer, vacuum dryer, one dimensional mixer, two dimensional mixer, three dimensional mixer, and high speed granulator and so on. These high-performance machines have extensive applications within industries such as food, medicine and chemical. Sustained development and a strong emphasis on research and technology have bolstered our quality standards. we seek to achieve the highest level of customer satisfaction through professionally developed drying ,mixing and granulating solutions. Hywell Machinery constant faith is providing perfect products to customer, excellenting service to customer !



OUR SERVICES
Pre-sale service
We Invite customers to visit our company and communicate on technical requirements face to face.
Sale service
Responsible for debugging the equipment according to customers' requirements of various technical data. Our engineers will train our customers about equipment features and operation key points to make sure the equipment running in the best condition.
After-sale service
We provide installation, debugging, maintenance, training and other services (Optional); Provide relevant technical data, equipment, software and related GMP certification materials;Set up after-sales service hotline, and arrange personnel to visit customers every year to know more customer needs,like customer operation problems in the process of production equipment.
Quality promise
Our company promises strictly operate the ISO9001 quality system certification standards and pharmaceutical equipment GMP audit requirements,promise we provide new equipment. Advanced technology,good quality.Equipment operation safe reliable, affordable, easy to maintain.

Equipment warranty period is one year,all the parts for the equipment choose well-known brand.
During the warranty when equipment have problem in quality like equipment failure and damage, our company offer free maintenance or replacement.

Industry standard Specification standard Drying weight per batch (Kg) Power (Kw) Steam consumption (Kg/h) Evaporation area (m2) Air capacity (m3 /h) Temperature error Baking plate Overall dimension (LxWxH) mm Baking cart (set)
RXH-7-D CT-C-O 60 0.75 12 7.1 3450 ±2 24 1400×1200×2000 1
RXH-14-D CT-C-I 120 0.75 18 14.1 3450 ±2 48 2300×1200×2000 2
RXH-27-D CT-C-II 240 0.75x2 36 28.3 6900 ±2 96 3300×2200×2000 4
RXH-41-D CT-C-III 360 0.75x3 60 42.4 10350 ±2 144 3550×2200×2000 6
RXH-54-D CT-C-IV 480 0.75x4 80 56.5 13800 ±2 192 4460×1000×2290 8

Mark

It also design and manufacture base customer require. Welcome to contact us!
