Customize ethanol distiller 95% alcohol recovery tower
Product Description
Customize ethanol Distiller 95% alcohol recovery tower
The device according to the user's requirements, may be about 30dilute alcohol distillation to 90_95alcohol. If the alcohol content of the finished product requirements are high, the reflux ratio can be ncreased, but the output will be decreased
The device uses an efficient metal stainless steel packing Distillation tower made of stainless steel, thereby preventing iron dogging
filler phenomenon, extending the life of the device. The device contact ethanol devices such as condensor, surge tank, cooling snake ppe are made of stainless steel, in order to ensure that the finished alcohol is not contaminated W type of stills with removable U-shaped heat pipe, in the maintenance of the U-shaped heat pipe can be removed from the autoclave, the ease of heating pipe outer wall and the inner wall of the distilation vessel cleaning
Customize ethanol distiller 95% alcohol recovery tower
| Model Item | HT200 | HT300 | HT400 | HT500 | HT600 | HT800 |
| Tower Capacity(L) | 640 | 1220 | 1450 | 2300 | 2500 | 3200 |
| Tower Height(mm) | 6000 | 7000 | 8000 | 8000 | 10000 | 12000 |
| Hight Level Tank Capacity(L) | 230 | 400 | 650 | 800 | 1000 | 1500 |
| Condensation Area(m²) | 9 | 11 | 22 | 25 | 40 | |
| Cooling Area(m²) | 1 | 1.5 | 2.2 | 6 | 8 | 15 |
| Heat Exchange Area(m²) | 3 | 6 | 12 | 17 | 25 | 30 |
| Recovery Capacity(kg/h) | 45-50 | 90-100 | 150-160 | 280-300 | 420-440 | 600-620 |
| Recovery Concentration(%) | >90℃-95℃ | |||||
| Packing Form | stainless steel corrugated plate packing | |||||
| Vessel Classification | Class D | |||||
| Weight(kg) | 1100 | 1900 | 2300 | 3800 | 4500 | 7800 |
| Size(mm) | 2300*700 *7300 | 2600*800 *7500 | 2500*1000 *9000 | 3000*1200 *9000 | 3500*1400 *9000 | 4200*1800 *1400 |
Product Categories : Alcohol Recovery Tower
